Concrete Solid and Hollow Block, Paving Stone, Interlock, Curbstone and Rainy Gutter Making Machine and Production Line Equipment
|
PRODUCT DESCRIPTION |
Concrete Solid and Hollow Block, Paving Stone, Interlock, Curbstone and Rainy Gutter Making Machine and Production Line Equipment |
||
|
OPERATION TYPE |
Full Automatic |
Semi-Automatic |
Manuel |
|
PRODUCTION RANGE |
One; - Concrete Block, Concrete Hollow Block, Concrete Paving Stone, Curbstone and Rainy Gutter Making Machine Alternatively; - Only Concrete Solid and Hollow Block Making Machine |
One; - Concrete Block, Concrete Hollow Block, Concrete Paving Stone, Curbstone and Rainy Gutter Making Machine Alternatively; - Only Concrete Solid and Hollow Block Making Machine |
One; - Concrete Block, Concrete Hollow Block, Concrete Paving Stone, Curbstone and Rainy Gutter Making Machine Alternatively; - Only Concrete Solid and Hollow Block Making Machine |
|
PRODUCT CAPACITY |
Approximately; - 10.000-25.000 pcs of 20*20*40 cm Sized of Block within 8 hours
- 700-1200 m² Interlock Paving Stone within 8 Hours
- 4.000-7.000 pcs of 15*30*70 cm Sized of Curbstone within 8 Hours |
Approximately; - 8.000-10.000 pcs of 20*20*40 cm Sized of Block within 8 hours
- 500-600 m² Interlock Paving Stone within 8 Hours
- 3.000-4.000 pcs of 15*30*70 cm Sized of Curbstone within 8 Hours |
Approximately; - 3.000-7.000 pcs of 20*20*40 cm Sized of Block within 8 hours
- 300-400 m² Interlock Paving Stone within 8 Hours
- 2.000-3.000 pcs of 15*30*70 cm Sized of Curbstone within 8 Hours |
|
MACHINE TYPE |
Optionally; Single Bunker Machine Double Bunker Machine |
Optionally; Single Bunker Machine Double Bunker Machine |
Optionally; Single Bunker Machine Double Bunker Machine |
|
PRESSING TYPE |
Optionally; Single Line Multi Line |
Single Line |
Single Line |
|
REQUIRED EMPLOYEE |
4-5 People |
7-9 People |
10-12 People |
|
ENERGY CONSUMPTION |
90-120 KW |
60-80 KW |
40-60 KW |
|
OTHER SPECIFICATION OF MACHINE |
Possible to Produce Styropor (Insulation) Hollow Blocks |
Possible to Produce Styropor (Insulation) Hollow Blocks |
Possible to Produce Styropor (Insulation) Hollow Blocks |
|
INCLUDING EQUIPMENT |
MAIN MACHINE (PRESSING PART) |
Including |
Including |
Including |
|
PALETTE ENTRANCE ELEVATOR |
Including |
Including |
Not Including |
|
|
PALETTE EXIT ELEVATOR |
Including (Not Available on the Multi Line Pressing Machine) |
Including |
Not Including |
|
|
DRY PRODUCT COLLECTING AND STOWING ROBOT |
Including (Not Available on the Multi Line Pressing Machine) |
Optional |
Not Including |
|
|
BATCHING MIXER |
Including (The Capacity Between 1-3 m³) |
Including (The Capacity Between 500-750 Litres) |
Including (The Capacity Between 100-500 Litres) |
|
|
CEMENT, WATER AND ADDITIVE MATERIAL WEIGHING SYSTEMS |
Including |
Not Including |
Not Including |
|
|
MORTAR CONVEYOR BELT |
Including |
Including |
Including |
|
|
SAND CONVEYOR BELT |
Including |
Including |
Including |
|
|
CEMENT SILO |
Including (The Capacity Between 45-120 ton) |
Optional (The Capacity Between 30-60 ton) |
Optional (The Capacity Between 15-45 ton) |
|
|
CEMENT SCREW CONVEYOR |
Including |
Optional |
Optional |
|
|
SAND (AGGREGATE) BUNKER |
Including (The Capacity Between 45-120 m³) |
Optional (The Capacity Between 30-60 m³) |
Optional (The Capacity Between 15-45 m³) |
|
|
SAND BUNKER WEIGHING BELT |
Including |
Optional |
Optional |
|
OTHER REQUIRED EQUIPMENT |
MOULD |
Required (Type and Number is Depending on Which Product will be Produced) |
Required (Type and Number is Depending on Which Product will be Produced) |
Required (Type and Number is Depending on Which Product will be Produced) |
|
PRODUCTION PALETTE |
Required (Minimum 2.000 Pcs-Section Legged Palette) |
Required (Minimum 1.000 Pcs-Section Legged Palette) |
Required (Minimum 1.000 Pcs) |
|
|
FORKLIFT |
Required (2 Pcs) |
Required (2 Pcs) |
Not Required (Palette Carrying Trolley is Used) |
|
|
COMMAND CABIN |
Required |
Not Required |
Not Required |
|
|
COMPRESSOR |
Required |
Not Required |
Not Required |
|
|
ELECTRICAL AND WATER INSTALLMENT |
Required |
Required |
Required |
|
|
HORIZONTAL AND VERTICAL PRODUCT STRAPPING EQUIPMENT |
Required |
Required |
Required |
|
OPTIONAL EQUIPMENT |
BATCHING (SECOND) MIXER FOR FINE (COLOURED) MATERIAL |
Available (Not Available on the Single Bunker Machine) |
Available (Not Available on the Single Bunker Machine) |
Not Available |
|
SECOND MORTAR AND SAND BELT (IF SECOND MIXER IS USED) |
Available |
Available |
Not Available |
|
|
FINGER CAR SYSTEM |
Available |
Not Available |
Not Available |
|
|
SHELF SYSTEM TO STOCK PRODUCTS |
Available |
Not Available |
Not Available |
|
|
FULL AUTOMATIC STRAPPING (PALLETIZING) SYSTEM |
Available |
Not Available |
Not Available |
 |
THE PRODUCTS
We proudly inform you about our product portfolio. Please see the products here. |
